• INA PCJ40XLNFA125 Four Bolt Cast Iron Square Housing with Eccentric Collar Insert and Anti-Corrosion Protection 40mm Bore
  • INA
1 2

SKU: PCJ40-XL-N-FA125-INA

INA PCJ40XLNFA125 Four Bolt Cast Iron Square Housing with Eccentric Collar Insert and Anti-Corrosion Protection 40mm Bore

INA PCJ40XLNFA125 Four Bolt Cast Iron Square Housing with Eccentric Collar Insert and Anti-Corrosion Protection 40mm Bore
$102.27 ex VAT
$102.27 ex VAT
Sale Sold out

In stock

Price Break
4+ $68.50
9+ $64.65
19+ $63.89
29+ $63.12
39+ $62.35
49+ $61.58
59+ $57.73
69+ $56.96
79+ $56.19
89+ $55.42
99+ $53.88

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
40mm
Style:
PCJ
Bolt Hole Centres:
101.5mm
Technical
d 40mm
L 130mm
U 56.8mm
A 34.5mm
A1 13mm
A2 24mm
B1 43.8mm
d3 max 58mm
J 101.5mm
N 14mm
Q M6
V 110mm
Mass 1.9 kg
Basic dynamic load rating Cr 34500 N
Basic static load rating Cor 19800 N
Designation of housing CJ08
Designation of bearing GRAE40-XL-NPP-B-FA125Bearing end cap, closed design (to be ordered separately)
KASK08 N/A
