• INA PCJ50-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 50mm Bore
  • INA
1 2

SKU: PCJ50-TV-FA125.5-INA

INA PCJ50-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 50mm Bore

INA PCJ50-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 50mm Bore
$139.62 ex VAT
$139.62 ex VAT
Sale Sold out

In stock

Price Break
4+ $93.52
9+ $88.27
19+ $87.22
29+ $86.17
39+ $85.11
49+ $84.06
59+ $78.81
69+ $77.76
79+ $76.71
89+ $75.66
99+ $73.56

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
50mm
Style:
PCJ
Bolt Hole Centres:
111mm
Technical
d 50mm
L 143mm
U 57.8mm
A 43mm
A1 21mm
A2 25mm
B1 43.8mm
d3 max 69mm
J 111mm
N 17mm
Q 1/4 - 28 UNF
V 111mm
Mass 1.32 kg
Basic dynamic load rating Cr 37500 N
Basic static load rating Cor 23200 N
Load carrying capacity of housing Cor G 19600 N
Designation of housing GEH.CJ10-TV
Designation of bearing GRAE50-NPP-B-FA107/125.5
Bearing end cap, closed design (supplied with end cap) KASK10-S-G
Bearing end cap, open design, with integral rotary shaft seal (available by agreement) KASK10-S-R-NBR
Back seal components RWDR10-R-NBR
