SKU: PHE25-TV-FA125.5-INA

INA PHE25TVFA125.5 Plastic Take Up Unit with Eccentric Collar Insert 25mm Bore

Name: INA PHE25TVFA125.5 Plastic Take Up Unit with Eccentric Collar Insert 25mm Bore
Brand: INA
SKU: PHE25-TV-FA125.5-INA
Price: 74.93 USD
Availability: InStock

$74.93 ex VAT

Sale Sold out

In stock

Price Break

4+ $50.19

9+ $47.37

19+ $46.80

29+ $46.24

39+ $45.68

49+ $45.11

59+ $42.29

69+ $41.73

79+ $41.16

89+ $40.60

99+ $39.47

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: INA - High Quality
Inside Diameter:: 25mm
Style:: PHE

Technical

d	25mm
L	99mm
M	74mm
A2	27.5mm
B1	31mm
d3 max	37.5mm
K	M16?
L1	63.5mm
Q	1/4 - 28 UNF?
S1	23.5mm
T	36mm
W	47mm
Mass	0.4 kg
Basic dynamic load rating Cr	14900 N
Basic static load rating Cor	7800 N
Load carrying capacity of housing Cor G	500000 N
Designation of housing	GEH.HE05-TV?
Designation of bearing	GRAE25-NPP-B-FA107/125.5?
Bearing end cap, closed design	KASK05-S-G?
Bearing end caps, open design, with integral rotary shaft seal (available by agreement)	KASK05-S-R-NBR?
