INA PHE40TVFA125.5 Plastic Take Up Unit with Eccentric Collar Insert 40mm Bore

Name: INA PHE40TVFA125.5 Plastic Take Up Unit with Eccentric Collar Insert 40mm Bore
Brand: INA
SKU: PHE40-TV-FA125.5-INA
Price: 121.71 USD
Availability: InStock

$121.71 ex VAT

Sale Sold out

In stock

Price Break

4+ $81.52

9+ $76.94

19+ $76.03

29+ $75.11

39+ $74.20

49+ $73.28

59+ $68.70

69+ $67.78

79+ $66.87

89+ $65.95

99+ $64.12

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: INA - High Quality
Inside Diameter:: 40mm
Style:: PHE

Technical

d	40mm
L	140mm
M	100mm
A2	34.5mm
B1	43.8mm
d3 max	58mm
K	M16?
L1	85mm
Q	1/4 - 28 UNF?
S1	32.8mm
T	40mm
W	80mm
Mass	1.02 kg
Basic dynamic load rating Cr	34500 N
Basic static load rating Cor	19800 N
Load carrying capacity of housing Cor G	11200 N
Designation of housing	GEH.HE08-TV?
Designation of bearing	GRAE40-NPP-B-FA107/125.5?
Bearing end cap, closed design	KASK08-S-G?
Bearing end caps, open design, with integral rotary shaft seal (available by agreement)	KASK08-S-R-NBR?
