SKU: PSHE35-TV-FA125.5-INA

INA PSHE35TVFA125.5 Plastic Threaded Base Plummer Block Housing with Eccentric Collar and Anti-Corrosion Protection 35mm Bore

Name: INA PSHE35TVFA125.5 Plastic Threaded Base Plummer Block Housing with Eccentric Collar and Anti-Corrosion Protection 35mm Bore
Brand: INA
SKU: PSHE35-TV-FA125.5-INA
Price: 110.20 USD
Availability: InStock

$110.20 ex VAT

Sale Sold out

In stock

Price Break

4+ $73.82

9+ $69.67

19+ $68.84

29+ $68.01

39+ $67.18

49+ $66.35

59+ $62.21

69+ $61.38

79+ $60.55

89+ $59.72

99+ $58.06

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: INA - High Quality
Inside Diameter:: 35mm
Style:: PSHE
Bolt Hole Centres:: 82.6mm

Technical

d	35mm
L	110mm
H2	95mm
A	47.5mm
B1	39mm
d3 max	51mm
H	47.6mm
J	82.6mm
K	M10
Q	1/4 - 28 UNF
S1	29.5mm
Mass	0.8 kg
Basic dynamic load rating Cr	27500 N
Basic static load rating Cor	15300 N
Load carrying capacity of housing Cor G	8000 N
Designation of housing	GEH.SHE07-TV
Designation of bearing	GRAE35-NPP-B-FA107/125.5
Bearing end cap, closed design	KASK07-S-G
Bearing end cap (available by agreement)	KASK07-S-R-NBR
