INA PTUE35TVFA125.5 Plastic Take Up Unit with Eccentric Collar Insert 35mm Bore

Name: INA PTUE35TVFA125.5 Plastic Take Up Unit with Eccentric Collar Insert 35mm Bore
Brand: INA
SKU: PTUE35-TV-FA125.5-INA
Price: 102.67 USD
Availability: InStock

$102.67 ex VAT

Sale Sold out

In stock

Price Break

4+ $68.77

9+ $64.91

19+ $64.13

29+ $63.36

39+ $62.59

49+ $61.82

59+ $57.95

69+ $57.18

79+ $56.41

89+ $55.63

99+ $54.09

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: INA - High Quality
Inside Diameter:: 35mm
Style:: PTUE

Technical

d	35mm
L	125mm
H	102.5mm
A1	12mm
A2	34.5mm
B1	39mm
d3 max	51mm
H1	89mm
K	M16?
L1	76mm
L3	63mm
Q	1/4 - 28 UNF?
S1	29.5mm
T	40mm
Mass	0.82 kg
Basic dynamic load rating Cr	27500 N
Basic static load rating Cor	15300 N
Load carrying capacity of housing Cor G	10700 N
Designation of housing	GEH.TUE07-TV?
Designation of bearing	GRAE35-NPP-B-FA107/125.5?
Bearing end cap, closed design	KASK07-S-G?
Bearing end caps, open design, with integral rotary shaft seal (available by agreement)	KASK07-S-R-NBR?
