• INA RA45XL Four Bolt Sheet Steel Round Housing with Eccentric Collar Insert 45mm Bore
  • INA
1 2

SKU: RA45-XL-INA

INA RA45XL Four Bolt Sheet Steel Round Housing with Eccentric Collar Insert 45mm Bore

INA RA45XL Four Bolt Sheet Steel Round Housing with Eccentric Collar Insert 45mm Bore
$69.30 ex VAT
$69.30 ex VAT
Sale Sold out

In stock

Price Break
4+ $46.42
9+ $43.81
19+ $43.29
29+ $42.77
39+ $42.25
49+ $41.73
59+ $39.12
69+ $38.60
79+ $38.08
89+ $37.56
99+ $36.51

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
45mm
Style:
RA
Pitch Circle Diameter:
120.5mm
Technical
d 45mm
H 149.2mm
B1 43.8mm
A 11.1mm
d3 max 63mm
J 120.5mm
N 13.5mm
Number of screw holes 4
S 3.5mm
U 36.2mm
V 95
Mass 1.41 kg
Load carrying capacity of housing Cor G 7700 N
Basic dynamic load rating Cr 34500 N
Basic static load rating Cor 20400 N
Designation of housing FLAN85-MSB (2 X)
Designation of bearing GRAE45-XL-NPP-B
