INA RALTR20XL Three Bolt Sheet Steel Triangle Housing with Eccentric Collar Insert 20mm Bore

Name: INA RALTR20XL Three Bolt Sheet Steel Triangle Housing with Eccentric Collar Insert 20mm Bore
Brand: INA
SKU: RALTR20-XL-INA
Price: 29.36 USD
Availability: InStock

$29.36 ex VAT

Sale Sold out

In stock

Price Break

4+ $19.67

9+ $18.56

19+ $18.34

29+ $18.12

39+ $17.90

49+ $17.68

59+ $16.58

69+ $16.35

79+ $16.13

89+ $15.91

99+ $15.47

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: INA - High Quality
Inside Diameter:: 20mm
Style:: RALTR
Pitch Circle Diameter:: 71.5mm

Technical

d	20mm
H	90.5mm
B1	24.5mm
A	7.2mm
d3 max	30mm
H1	33.3mm
H2	76.2mm
J	71.5mm
N	8.7mm
S1	2mm
U	20.6mm
V	49mm
Mass	0.21 kg
Load carrying capacity of housing Cor G	2600 N
Basic dynamic load rating Cr	500000 N
Basic static load rating Cor	5000 N
Designation of housing	FLAN42-LSTR (2 X)
Designation of bearing	RALE20-XL-NPP-B
