SKU: RCJY40-TV-VA-INA

INA RCJY40-TV-VA Four Bolt Plastic Square Housing with Grub Screw Insert Corrosion-Resistant Design 40mm Bore

Name: INA RCJY40-TV-VA Four Bolt Plastic Square Housing with Grub Screw Insert Corrosion-Resistant Design 40mm Bore
Brand: INA
SKU: RCJY40-TV-VA-INA
Price: 213.77 USD
Availability: InStock

$213.77 ex VAT

Sale Sold out

In stock

Price Break

4+ $143.19

9+ $135.15

19+ $133.54

29+ $131.93

39+ $130.32

49+ $128.71

59+ $120.67

69+ $119.06

79+ $117.45

89+ $115.84

99+ $112.62

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: INA - High Quality
Inside Diameter:: 40mm
Style:: RCJY
Bolt Hole Centres:: 102mm

Technical

d	40mm
L	130mm
U	53.2mm
A	37.5mm
A1	17mm
A2	23mm
B	49.2mm
J	102mm
N	14mm
Q	1/4 - 28 UNF
V	99mm
Mass	1.04 kg
Basic dynamic load rating Cr	31500 N
Basic static load rating Cor	18900 N
Load carrying capacity of housing Cor G	19200 N
Designation of housing	GEH.CJ08-TV
Designation of bearing	GYE40-KRR-B-FA107-VA
Bearing end cap, closed design (supplied with end cap)	KASK08-S-G
Bearing end cap, open design, with integral rotary shaft seal (available by agreement)	KASK08-S-R-NBR
