• SBLF202 Metric Two Bolt Cast Iron Oval Housing with 15mm Bore Grub Screw Insert
1 1

SKU: SBLF.202

SBLF202 Metric Two Bolt Cast Iron Oval Housing with 15mm Bore Grub Screw Insert

SBLF202 Metric Two Bolt Cast Iron Oval Housing with 15mm Bore Grub Screw Insert
$15.64 ex VAT
$15.64 ex VAT
Sale Sold out

In stock

Price Break
3+ $10.47
4+ $9.88
9+ $9.76
19+ $9.65
49+ $9.53
99+ $9.41
499+ $8.82
999+ $8.71
1999+ $8.59
2999+ $8.47
4999+ $8.24

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SBLF Series 2 Bolt Oval Cast Iron Housings: Normal duty bearing unit supplied with a fully sealed flat back bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, Re-lubricateable, replaceable insert, grub screw fixing, flat back of bearing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
15mm
Style:
SBLF
Bolt Hole Centres:
63.5mm
Technical
d 15mm
a 81mm
e 63.5mm
b 56mm
i 9.5mm
s 8mm
g 9.5mm
l 18mm
Bolt M6
z 25.5mm
n 6mm
Weight 0.3 kg
Dynamic load 760 kgf
Static load 450 kgf
