• SER204 Metric Bearing Insert and Snap Ring 20mm Bore 47mm Outside Dia
  • SER204 Metric Bearing Insert and Snap Ring 20mm Bore 47mm Outside Dia
1 2

SKU: SER.204

SER204 Metric Bearing Insert and Snap Ring 20mm Bore 47mm Outside Dia

SER204 Metric Bearing Insert and Snap Ring 20mm Bore 47mm Outside Dia
$13.25 ex VAT
$13.25 ex VAT
Sale Sold out

In stock

Price Break
3+ $8.87
4+ $8.37
9+ $8.27
19+ $8.17
49+ $8.07
99+ $7.97
499+ $7.47
999+ $7.37
1999+ $7.27
2999+ $7.18
4999+ $6.98

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SER or 11--CG Series Normal Duty Bearing Insert: This insert type is a fully sealed bearing with a parallel outer diameter and comes fitted with a snap ring, they have the benefit of being re-lubricatable after installation. There are 2 grub screws to allow tightening against the shaft once fitted.
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
20mm
Outside Diameter:
47mm
Style:
SER
Technical
d 20mm
D 47mm
Bi 31mm
Be 15.9mm
n 12.7mm
m 18.3mm
E 12.09mm
a 1.07mm
h 4mm
R 4.14mm
J 2.46mm
P 52.7mm
G 4.8mm
Grub screw M6X1.0
Weight 0.22 kg
Dynamic load 1010 kgf
Static load 630 kgf
Rec max speed 7450 rpm
