• SER206-20 Imperial Bearing Insert and Snap Ring 1-1/4 inch Bore 62mm Outside Dia
  • SER206-20 Imperial Bearing Insert and Snap Ring 1-1/4 inch Bore 62mm Outside Dia
1 2

SKU: SER.206-20

SER206-20 Imperial Bearing Insert and Snap Ring 1-1/4 inch Bore 62mm Outside Dia

SER206-20 Imperial Bearing Insert and Snap Ring 1-1/4 inch Bore 62mm Outside Dia
$21.43 ex VAT
$21.43 ex VAT
Sale Sold out

In stock

Price Break
3+ $14.35
4+ $13.55
9+ $13.38
19+ $13.22
49+ $13.06
99+ $12.90
499+ $12.09
999+ $11.93
1999+ $11.77
2999+ $11.61
4999+ $11.29

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SER or 11--CG Series Normal Duty Bearing Insert: This insert type is a fully sealed bearing with a parallel outer diameter and comes fitted with a snap ring, they have the benefit of being re-lubricatable after installation. There are 2 grub screws to allow tightening against the shaft once fitted.
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
31.75mm = 1.25 (1-1/4) inch
Outside Diameter:
62mm
Style:
SER
Technical
d 1-1/4 inch
D 62mm
Bi 38.1mm
Be 22.2mm
n 15.9mm
m 22.2mm
E 17.02mm
a 1.65mm
h 5.6mm
R 5.92mm
J 3.28mm
P 67.7mm
G 5.6mm
Grub screw M6X1.0
Weight 0.39 kg
Dynamic load 1530 kgf
Static load 1020 kgf
