SKU: SILKAC8M-CDX
Codex SILKAC8M Left Hand Steel / Bronze Lined Plain Female Rod End M8 Thread
- Regular price
- $14.04 ex VAT
- Sale price
- $14.04
- Regular price
-
In stock
Quantity Price Breaks
10
$12.50
19
$11.79
29
$11.65
39
$11.51
49
$11.37
74
$11.23
99
$10.53
199
$10.39
249
$10.25
499
$10.11
999
$9.83
SKU:
SILKAC8M-CDX
Codex SILKAC8M Left Hand Steel / Bronze Lined Plain Female Rod End M8 Thread
- Regular price
- $14.04 ex VAT
- Sale price
- $14.04
- Regular price
-
Description
|
SIKAC..M Series Rod End Bearings:These rod end bearings comprise of sliding contact surfaces of steel against bronze. They are unsealed and although they are low maintenance they may require re-lubrication from time to time via the re lubrication point in the side of the head this will serve to extend it's life cycle. Operating temperatures are within -30deg C to +180 deg C. Left and Right hand threaded versions are available an L in the part number denotes the left hand option. These are metric sized rod end bearings. Application: Lower load carrying capacity compared to steel/steel rod ends, but more suitable for applications where lubricant starvation might occur. Benefits: Lower maintenance. |
Technical
| d | = | 8mm |
| d2 max | = | 25mm |
| G | = | M8 |
| B | = | 12mm |
| C1 max | = | 9mm |
| h1 | = | 36mm |
| Max misalignment angle | = | 14 degrees |
| Dynamic load | = | 7.2 kN |
| Static load | = | 9.15 kN |
| dk | = | 15.8mm |
| d3 | = | 12.5mm |
| d4 max | = | 17mm |
| l3 min | = | 12mm |
| l4 max | = | 50mm |
| l5 | = | 5mm |
| l7 min | = | 12mm |
| r1 min | = | 0.3mm |
| w | = | 14mm |
| Weight | = | 0.043 kg |
