• RHP SNP25EC Threaded Base Small Footprint Pillow / Plummer Block and 25mm Bore Flat Back Collar Insert
1 1

SKU: SNP25EC-RHP

RHP SNP25EC Threaded Base Small Footprint Pillow / Plummer Block and 25mm Bore Flat Back Collar Insert

RHP SNP25EC Threaded Base Small Footprint Pillow / Plummer Block and 25mm Bore Flat Back Collar Insert
$61.37 ex VAT
$61.37 ex VAT
Sale Sold out

In stock

Price Break
10+ $41.10
20+ $38.80
30+ $38.33
40+ $37.87
50+ $37.41
75+ $36.95
100+ $34.64
200+ $34.18
250+ $33.72
500+ $33.25
1000+ $32.33

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
25mm
Style:
SNP
Bolt Hole Centres:
50.8mm
Technical
Bore 25mm
L 80mm
H 36.5mm
H1 13.5mm
H2 71.5mm
J 50.8mm
Threads M10x1.50
A 36mm
A1 25mm
B2 30.92mm
s1 7.57mm
d2 38.1mm
Dynamic load Cr 14000 N
Static load Cor 7880 N
Rec max speed 6250 rpm
Weight 1.2 kg
Insert <a href="advanced_search_result.php?keywords=1225-25ECG+insonly">1225-25ECG Click Here</a>
Casting group 3
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
