SKU: SS20DP/50B-0.5_INCH

SS20DP/50B-0.5 Imperial EN8 Steel Spur Gear 50 Tooth 20 DP Bored 0.5 inch (H8)

Name: SS20DP/50B-0.5 Imperial EN8 Steel Spur Gear 50 Tooth 20 DP Bored 0.5 inch (H8)
Brand: Drive-Flex
SKU: SS20DP/50B-0.5_INCH
Price: 93.23 USD
Availability: InStock

$93.23 ex VAT

Sale Sold out

In stock

Price Break

5+ $62.45

9+ $58.94

19+ $58.24

29+ $57.54

49+ $56.84

74+ $56.14

99+ $52.63

199+ $51.93

249+ $51.23

499+ $50.52

999+ $49.12

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 12.7mm = 0.5 (1/2) inch
Number of Teeth:: 50
Variant:: Tooth Profile B
Pitch Circle Diameter:: 63.5mm = 2.5 (2-1/2) inch
Gear Modulus:: 20DP

Technical

Number of Teeth	50
Pitch (dp)	2.5 inch
Bore (H8)	0.5 inch
Hub / Boss (dm)	1 inch
Outside (de)	2.6 inch
Width (A)	1 inch
Face Width (B)	0.375 inch
Modulus / Diametral Pitch DP	20 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees
