SKU: SS20DP/64B-0.5_INCH

SS20DP/64B-0.5 Imperial EN8 Steel Spur Gear 64 Tooth 20 DP Bored 0.5 inch (H8)

Name: SS20DP/64B-0.5 Imperial EN8 Steel Spur Gear 64 Tooth 20 DP Bored 0.5 inch (H8)
Brand: Drive-Flex
SKU: SS20DP/64B-0.5_INCH
Price: 100.73 USD
Availability: InStock

$100.73 ex VAT

Sale Sold out

In stock

Price Break

5+ $67.47

9+ $63.68

19+ $62.92

29+ $62.16

49+ $61.41

74+ $60.65

99+ $56.86

199+ $56.10

249+ $55.34

499+ $54.58

999+ $53.07

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 12.7mm = 0.5 (1/2) inch
Number of Teeth:: 64
Variant:: Tooth Profile B
Pitch Circle Diameter:: 81.28mm = 3.2 inch
Gear Modulus:: 20DP

Technical

Number of Teeth	64
Pitch (dp)	3.2 inch
Bore (H8)	0.5 inch
Hub / Boss (dm)	1 inch
Outside (de)	3.3 inch
Width (A)	1 inch
Face Width (B)	0.375 inch
Modulus / Diametral Pitch DP	20 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees
