• SSUCF201 Metric Four Bolt Square Stainless Steel Flange Housing with 12mm Bore Stainless Insert
1 1

SKU: SSUCF.201

SSUCF201 Metric Four Bolt Square Stainless Steel Flange Housing with 12mm Bore Stainless Insert

SSUCF201 Metric Four Bolt Square Stainless Steel Flange Housing with 12mm Bore Stainless Insert
$57.20 ex VAT
$57.20 ex VAT
Sale Sold out

In stock

Price Break
3+ $38.32
4+ $36.17
9+ $35.74
19+ $35.30
49+ $34.87
99+ $34.44
499+ $32.29
999+ $31.86
1999+ $31.43
2999+ $31.00
4999+ $30.14

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable
Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request.
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
12mm
Style:
SSUCF
Bolt Hole Centres:
64mm
Technical
d 12mm
a 86mm
e 64mm
i 15mm
g 12mm
L 25.4mm
S 12mm
Z 33.3mm
Bi 31mm
n 12.7mm
Bolt 10mm
Weight 0.63 kg
Dynamic load 1000 kgf
Static load 630 kgf
