SKU: SSUCF.201-8

SSUCF201-8 Imperial Four Bolt Square Stainless Steel Flange Housing with 1/2 inch Bore Stainless Insert

Name: SSUCF201-8 Imperial Four Bolt Square Stainless Steel Flange Housing with 1/2 inch Bore Stainless Insert
Brand: Gen
SKU: SSUCF.201-8
Price: 49.81 USD
Availability: InStock

$49.81 ex VAT

Sale Sold out

In stock

Price Break

3+ $33.36

4+ $31.49

9+ $31.11

19+ $30.74

49+ $30.36

99+ $29.99

499+ $28.11

999+ $27.74

1999+ $27.36

2999+ $26.99

4999+ $26.24

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable
Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request.

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 12.7mm = 0.5 (1/2) inch
Style:: SSUCF
Bolt Hole Centres:: 64mm

Technical

d	1/2 inch
a	86mm
e	64mm
i	15mm
g	12mm
L	25.4mm
S	12mm
Z	33.3mm
Bi	31mm
n	12.7mm
Bolt	10mm
Weight	0.63 kg
Dynamic load	1000 kgf
Static load	630 kgf

Reviews

View full details
