SKU: SSUCF.206-18
SSUCF206-18 Imperial Four Bolt Square Stainless Steel Flange Housing with 1-1/8 inch Bore Stainless Insert
SSUCF206-18 Imperial Four Bolt Square Stainless Steel Flange Housing with 1-1/8 inch Bore Stainless Insert
Regular price
$105.63
ex VAT
Regular price
Sale price
$105.63
ex VAT
In stock
Price Break
3+
$70.75
4+
$66.78
9+
$65.98
19+
$65.19
49+
$64.39
99+
$63.60
499+
$59.62
999+
$58.83
1999+
$58.03
2999+
$57.24
4999+
$55.65
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 28.58mm = 1.125 (1-1/8) inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 83mm
Technical
Technical
| d | 1-1/8 inch |
|---|---|
| a | 108mm |
| e | 83mm |
| i | 18mm |
| g | 14mm |
| L | 31mm |
| S | 12mm |
| Z | 40.2mm |
| Bi | 38.1mm |
| n | 15.9mm |
| Bolt | 10mm |
| Weight | 1.1 kg |
| Dynamic load | 1520 kgf |
| Static load | 1020 kgf |
