SKU: SSUCF.218
SSUCF218 Metric Four Bolt Square Stainless Steel Flange Housing with 90mm Bore Stainless Insert - Allow 2-3 Days
SSUCF218 Metric Four Bolt Square Stainless Steel Flange Housing with 90mm Bore Stainless Insert - Allow 2-3 Days
Regular price
$745.27
ex VAT
Regular price
Sale price
$745.27
ex VAT
In stock
Price Break
3+
$532.78
4+
$504.74
9+
$476.70
19+
$448.66
49+
$437.44
99+
$426.22
499+
$370.14
999+
$0.00
1999+
$0.00
2999+
$0.00
4999+
$0.00
Quantity
Couldn't load pickup availability
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 90mm
- Style:
- SSUCF
- Bolt Hole Centres:
- 187mm
Technical
Technical
| d | 90mm |
|---|---|
| a | 235mm |
| e | 187mm |
| i | 42mm |
| g | 26mm |
| L | 70mm |
| S | 23mm |
| Z | 98.3mm |
| Bi | 96mm |
| n | 39.7mm |
| Bolt | 20mm |
| Weight | 11.3 kg |
| Dynamic load | 7500 kgf |
| Static load | 6170 kgf |
