• SSUCT209 Metric Stainless Steel Take Up Unit Housing with 45mm Bore Stainless Insert
1 1

SKU: SSUCT.209

SSUCT209 Metric Stainless Steel Take Up Unit Housing with 45mm Bore Stainless Insert

SSUCT209 Metric Stainless Steel Take Up Unit Housing with 45mm Bore Stainless Insert
$232.95 ex VAT
$232.95 ex VAT
Sale Sold out

Equivalent to: ST45

In stock

Price Break
3+ $156.03
4+ $147.27
9+ $145.51
19+ $143.76
49+ $142.01
99+ $140.25
499+ $131.49
999+ $129.74
1999+ $127.98
2999+ $126.23
4999+ $122.72

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable
Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request.
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
45mm
Style:
SSUCT
Technical
d 45mm
o 19mm
g 16mm
p 83mm
q 49mm
s 29mm
b 83mm
K 16mm
e 102mm
a 117mm
w 144mm
j 49mm
l 35mm
h 87mm
Bi 49.2mm
n 19mm
Weight 2.4 kg
Dynamic load 2560 kgf
Static load 1810 kgf
Rec max speed 3700 rpm
