• SSUCT212 Metric Stainless Steel Take Up Unit Housing with 60mm Bore Stainless Insert
1 1

SKU: SSUCT.212

SSUCT212 Metric Stainless Steel Take Up Unit Housing with 60mm Bore Stainless Insert

SSUCT212 Metric Stainless Steel Take Up Unit Housing with 60mm Bore Stainless Insert
$268.21 ex VAT
$268.21 ex VAT
Sale Sold out

Equivalent to: ST60

In stock

Price Break
3+ $179.63
4+ $169.54
9+ $167.52
19+ $165.50
49+ $163.48
99+ $161.46
499+ $151.37
999+ $149.35
1999+ $147.33
2999+ $145.32
4999+ $141.28

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable
Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request.
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
60mm
Style:
SSUCT
Technical
d 60mm
o 32mm
g 19mm
p 102mm
q 64mm
s 35mm
b 102mm
K 22mm
e 130mm
a 146mm
w 194mm
j 64mm
l 46mm
h 119mm
Bi 65.1mm
n 25.4mm
Weight 5.0 kg
Dynamic load 4100 kgf
Static load 3150 kgf
Rec max speed 2800 rpm
