• Major Brand STO45 Support Roller Without Axial Guidance With Inner Sleeve 45x85x19.8mm
1 1

SKU: STO45-MB

Major Brand STO45 Support Roller Without Axial Guidance With Inner Sleeve 45x85x19.8mm

Major Brand STO45 Support Roller Without Axial Guidance With Inner Sleeve 45x85x19.8mm
$154.83 ex VAT
$154.83 ex VAT
Sale Sold out

In stock

Price Break
10+ $103.71
19+ $97.89
29+ $96.72
39+ $95.56
49+ $94.39
74+ $93.23
99+ $87.40
199+ $86.23
249+ $85.07
499+ $83.90
999+ $81.57

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

Support Rollers without Axial Guidance : Designed for applications where the associated components can be designed to to provide the axial guidance. The support rollers are supplied with inner rings and are intended for arrangements where the pin or shaft can be hardened and ground.
Benefits: Supplied with the inner ring, separable - easily mounted

Brand / Quality:
Major Brand - High Quality
Inside Diameter:
45mm
Outside Diameter:
85mm
Width:
19.8mm
Technical
d 45mm
D 85mm
C 19.8mm
B 20mm
F 55mm
E 63mm
r min 1mm
r1r2 min 1mm
Speed rating 750 rpm
Dynamic load 25100 N
Basic static load 43000 N
Fatigue load limit Pu 5300 N
Max radial dynamic force 34500 N
Max radial static force 50000 N
Weight 580 g
