• SUCFPL202 Metric Four Bolt Square Thermo Plastic Flange Housing with 15mm Bore Stainless Insert
1 1

SKU: SUCF.PL.202

SUCFPL202 Metric Four Bolt Square Thermo Plastic Flange Housing with 15mm Bore Stainless Insert

SUCFPL202 Metric Four Bolt Square Thermo Plastic Flange Housing with 15mm Bore Stainless Insert
$46.32 ex VAT
$46.32 ex VAT
Sale Sold out

In stock

Price Break
3+ $31.03
4+ $29.29
9+ $28.94
19+ $28.59
49+ $28.24
99+ $27.89
499+ $26.15
999+ $25.80
1999+ $25.45
2999+ $25.10
4999+ $24.40

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFPL or PSF Series Thermo-Plastic 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the plastic housing which has pre-fitted anti crush stainless steel inserts in the bolt holes and also includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved
Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Colour may vary.
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
15mm
Temperature Range:
-35 to 102 deg C
Style:
SUCF
Bolt Hole Centres:
64mm
Technical
d 15mm
a 86mm
e 64mm
i 15mm
g 12mm
L 25.6mm
S 12mm
Z 33.3mm
Bi 31mm
n 12.7mm
Bolt 10mm
Weight 0.63 kg
Dynamic load 1000 kgf
Static load 630 kgf
Temperature Range -35 to 102 deg C
