• SUCFPL209-26 Imperial Four Bolt Square Thermo Plastic Flange Housing with 1-5/8 inch Bore Stainless Insert
1 1

SKU: SUCF.PL.209-26

SUCFPL209-26 Imperial Four Bolt Square Thermo Plastic Flange Housing with 1-5/8 inch Bore Stainless Insert

SUCFPL209-26 Imperial Four Bolt Square Thermo Plastic Flange Housing with 1-5/8 inch Bore Stainless Insert
$101.67 ex VAT
$101.67 ex VAT
Sale Sold out

In stock

Price Break
3+ $68.10
4+ $64.28
9+ $63.51
19+ $62.75
49+ $61.98
99+ $61.22
499+ $57.39
999+ $56.63
1999+ $55.86
2999+ $55.09
4999+ $53.56

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFPL or PSF Series Thermo-Plastic 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the plastic housing which has pre-fitted anti crush stainless steel inserts in the bolt holes and also includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved
Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Colour may vary.
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
41.28mm = 1.625 (1-5/8) inch
Temperature Range:
-35 to 102 deg C
Style:
SUCF
Bolt Hole Centres:
105mm
Technical
d 1-5/8 inch
a 137mm
e 105mm
i 22mm
g 18mm
L 38mm
S 16mm
Z 52.2mm
Bi 49.2mm
n 19mm
Bolt 14mm
Weight 2.3 kg
Dynamic load 2560 kgf
Static load 1810 kgf
Temperature Range -35 to 102 deg C
