SKU: SUCNFL207FG1-SNR

SNR SUCNFL207FG1 Metric Sentinel Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with35mm Bore Insert - Allow 2-3 Days

SNR SUCNFL207FG1 Metric Sentinel Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with35mm Bore Insert - Allow 2-3 Days
Regular price $235.52 ex VAT
Regular price Sale price $235.52 ex VAT
Sale Sold out

In stock

Price Break
3+ $175.46
4+ $168.37
9+ $164.82
19+ $159.51
49+ $155.96
99+ $147.10
499+ $124.06
999+ $0.00
1999+ $0.00
2999+ $0.00
4999+ $0.00
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Bore 35mm
A - Housing height 32.8mm
A1 - Housing foot height / flange height 16.1mm
A2 - Total height from mounting surface 43.4mm
B - Width of Inner Ring 42.9mm
d - Shaft diameter 35mm
e - Distance mounting surface to bearing centre 18mm
H - Housing length, width or diameter 163mm
J - Mounting holes distance 130mm
L - Housing width / diameter 90mm
N - Mounting hole dimension 13mm
S - Distance front side/bearing centre 17.5mm
C - Dynamic load rating 25.6 kN
C0 - Static load rating 15.3 kN
Operating temperature min. -10 Deg C
Operating temperature max. 80 Deg C
Mass 0.62kg
Recommended tightening torque for set screw 8.3 Nm
