SKU: SUCNFL210FG1-SNR

SNR SUCNFL210FG1 Metric Sentinel Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with50mm Bore Insert - Allow 2-3 Days

SNR SUCNFL210FG1 Metric Sentinel Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with50mm Bore Insert - Allow 2-3 Days
Regular price $353.50 ex VAT
Regular price Sale price $353.50 ex VAT
Sale Sold out

In stock

Price Break
3+ $263.35
4+ $252.71
9+ $247.39
19+ $239.41
49+ $234.09
99+ $220.79
499+ $186.21
999+ $0.00
1999+ $0.00
2999+ $0.00
4999+ $0.00
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Bore 50mm
A - Housing height 43mm
A1 - Housing foot height / flange height 21mm
A2 - Total height from mounting surface 57.6mm
B - Width of Inner Ring 51.6mm
d - Shaft diameter 50mm
e - Distance mounting surface to bearing centre 25mm
H - Housing length, width or diameter 197mm
J - Mounting holes distance 157mm
L - Housing width / diameter 115mm
N - Mounting hole dimension 17mm
S - Distance front side/bearing centre 19mm
C - Dynamic load rating 35 kN
C0 - Static load rating 23.1 kN
Operating temperature min. -10 Deg C
Operating temperature max. 80 Deg C
Mass 1.92kg
Recommended tightening torque for set screw 8.3 Nm
