SKU: SYF35FM-SKF
SKF SYF35FM Small Footprint Cast Iron Plummer Block with Eccentric Collar 35mm Insert
SKF SYF35FM Small Footprint Cast Iron Plummer Block with Eccentric Collar 35mm Insert
Regular price
$113.05
ex VAT
Regular price
Sale price
$113.05
ex VAT
In stock
Price Break
10+
$75.72
20+
$71.47
30+
$70.62
40+
$69.77
50+
$68.92
75+
$68.07
100+
$63.81
200+
$62.96
250+
$62.11
500+
$61.26
1000+
$59.56
Quantity
Couldn't load pickup availability
Description
Description
|
SKF Y-bearing Plummer Block Units with a Shortened Cast Housing and Locking Collar: These units contain a grey cast iron housing with a grease fitting in the housing which allows it to be re-lubricated. This makes them suitable for bearing arrangements that operate in high levels of contamination, high speeds, high temperatures or relatively heavy loads. The housing design has a shortened base that contains two threaded holes in the support base. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 35mm
- Style:
- SYF
- Bolt Hole Centres:
- 82.6mm
Technical
Technical
| d | 35mm |
|---|---|
| A | 45mm |
| A1 | 27mm |
| B1 | 38.9mm |
| H | 93mm |
| H1 | 47.6mm |
| J | 82.6mm |
| L | 103mm |
| G | M10 |
| G1 | 15mm |
| s1 | 29.4mm |
| Static load Cr | 15.3 kN |
| Dynamic load Cor | 25.5 kN |
| Fatigue load limit Pu | 0.655 kN |
| Limiting speed | 5300 rpm |
| Weight | 1.2 kg |
| Housing | SYF507 |
| Insert | YET207 |
