SKU: SYF40FM-SKF
SKF SYF40FM Small Footprint Cast Iron Plummer Block with Eccentric Collar 40mm Insert
SKF SYF40FM Small Footprint Cast Iron Plummer Block with Eccentric Collar 40mm Insert
Regular price
$120.82
ex VAT
Regular price
Sale price
$120.82
ex VAT
In stock
Price Break
10+
$80.92
20+
$76.38
30+
$75.47
40+
$74.56
50+
$73.65
75+
$72.74
100+
$68.19
200+
$67.29
250+
$66.38
500+
$65.47
1000+
$63.65
Quantity
Couldn't load pickup availability
Description
Description
|
SKF Y-bearing Plummer Block Units with a Shortened Cast Housing and Locking Collar: These units contain a grey cast iron housing with a grease fitting in the housing which allows it to be re-lubricated. This makes them suitable for bearing arrangements that operate in high levels of contamination, high speeds, high temperatures or relatively heavy loads. The housing design has a shortened base that contains two threaded holes in the support base. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 40mm
- Style:
- SYF
- Bolt Hole Centres:
- 88.9mm
Technical
Technical
| d | 40mm |
|---|---|
| A | 48mm |
| A1 | 30mm |
| B1 | 43.7mm |
| H | 99mm |
| H1 | 49.2mm |
| J | 88.9mm |
| L | 116mm |
| G | M12 |
| G1 | 20mm |
| s1 | 32.7mm |
| Static load Cr | 19 kN |
| Dynamic load Cor | 30.7 kN |
| Fatigue load limit Pu | 0.3 kN |
| Limiting speed | 4800 rpm |
| Weight | 1.5 kg |
| Housing | SYF508 |
| Insert | YET208 |
