SKU: TEN-ARM-SE11-DUN
Dunlop SE11 Chain and V-Belt Tension Arm
- Regular price
- $29.53 ex VAT
- Sale price
- $29.53
- Regular price
-
In stock
Quantity Price Breaks
3
$26.28
5
$24.81
9
$24.51
19
$24.21
49
$23.92
74
$23.62
99
$22.15
199
$21.85
249
$21.56
499
$21.26
999
$20.67
SKU:
TEN-ARM-SE11-DUN
Dunlop SE11 Chain and V-Belt Tension Arm
- Regular price
- $29.53 ex VAT
- Sale price
- $29.53
- Regular price
-
Description
Dunlop Chain and V-Belt Tension Arm: The tensioning element with the specification SE (SE 11 to SE 45) is the mostly used standard unit for tensioning all kinds of chain and belt drives.
Benefits: Suitable for applications in temperature range from -40 deg C to +80 deg C
Technical
| Part No. | = | SE11 |
| D | = | 35mm |
| E | = | 51 (+1/-0.5)mm |
| G | = | 5mm |
| H | = | M6 |
| J< | = | sup> |
| 1< | = | /sup> |
| = | 80mm | |
| J< | = | sup> |
| 2< | = | /sup> |
| = | 60mm | |
| K | = | 20mm |
| L | = | 90mm |
| M | = | 20mm |
| N | = | 22mm |
| O | = | 6mm |
| P | = | 8mm |
| T | = | 8.5mm |
| U | = | 16.5mm |
