SKU: TSFL30R-ISB
ISB TSFL30R Left Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M30 Thread
ISB TSFL30R Left Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M30 Thread
Equivalent to: TSFL30R
Out of stock
Share this product
Description
Description
TSF - TSM Series Rod End Bearings:: This series is constructed with C 45 improved and forged steel; the surfaces are protected from external corrosive agents, thanks to a galvanised zinc covering. They are available with internal and external threading, to the right and the left and they are provided with greasers or bores for lubrication.
- Brand / Quality:
- ISB-Good Quality
- Thread Size:
- M30x2
- Thread M / F:
- Female
- Thread Direction:
- Left Hand
- Bore:
- 30
- Inside Diameter:
- 30
- Material:
- Steel/PTFE Lined
Technical
Technical
| d | 30mm |
|---|---|
| d1 | 34.8mm |
| d2 | 67mm |
| d3 | M 30x2mm |
| d4 | 40mm |
| d5 | 50mm |
| B | 37mm |
| C1 | 24mm |
| h1 | 110mm |
| I3 | 56mm |
| I5 | 15mm |
| P | 15mm |
| W | 41mm |
| Ø | 50.8mm |
| α | 15° |
| Static C0 | 63.74KN |
| Weight | 1.02Kg |
