SKU: TSM4R-ISB
ISB TSM4R Right Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M4 Thread
ISB TSM4R Right Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M4 Thread
Equivalent to: TSM4R
Out of stock
Share this product
Description
Description
TSF - TSM Series Rod End Bearings:: This series is constructed with C 45 improved and forged steel; the surfaces are protected from external corrosive agents, thanks to a galvanised zinc covering. They are available with internal and external threading, to the right and the left and they are provided with greasers or bores for lubrication.
- Brand / Quality:
- ISB-Good Quality
- Thread Size:
- M4x0.7
- Thread M / F:
- Male
- Thread Direction:
- Right Hand
- Bore:
- 4
- Inside Diameter:
- 4
- Material:
- Steel/PTFE Lined
Technical
Technical
| d | 4mm |
|---|---|
| d1 | 7.6mm |
| d2 | 14mm |
| d3 | M 4x0.7mm |
| B | 7mm |
| C1 | 5.3mm |
| h1 | 30mm |
| I3 | 17mm |
| P | 3mm |
| Ø | 10.32mm |
| α | 13° |
| Static C0 | 2.94KN |
| Weight | 0.007Kg |
