SKU: TUJ25TF-SKF
SKF TUJ25TF Grub Screw Type Take Up Unit 25mm Bore
SKF TUJ25TF Grub Screw Type Take Up Unit 25mm Bore
Regular price
$69.13
ex VAT
Regular price
Sale price
$69.13
ex VAT
In stock
Price Break
10+
$46.31
20+
$43.71
30+
$43.19
40+
$42.66
50+
$42.14
75+
$41.62
100+
$39.02
200+
$38.50
250+
$37.98
500+
$37.46
1000+
$36.42
Quantity
Couldn't load pickup availability
Description
Description
|
SKF Y-bearing Take-Up Units with Cast Housing and Grub Screws: This unit consists of a cast housing and an insert bearing. They are typically mounted in take-up frames and connected by an adjustment screw. A grease fitting is provided in the housing for re-lubrication. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 25mm
- Style:
- TUJ
Technical
Technical
| d | 25mm |
|---|---|
| A | 34mm |
| A1 | 12mm |
| A2 | 25mm |
| B | 34.1mm |
| D1 | 19mm |
| H | 91mm |
| H1 | 76mm |
| H2 | 53mm |
| L | 100mm |
| L1 | 64mm |
| L2 | 10mm |
| L3 | 52mm |
| N | 33mm |
| N1 | 16mm |
| s1 | 19.8mm |
| Static load Cr | 7.8 kN |
| Dynamic load Cor | 14 kN |
| Fatigue load limit Pu | 0.335 kN |
| Limiting speed | 7000 rpm |
| Weight | 0.82 kg |
