• Challenge UC204-12 Imperial Insert with Grub Screws with 3/4 inch Bore 47mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge UC204-12 Imperial Insert with Grub Screws with 3/4 inch Bore 47mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge
1 3

SKU: UC.204-12.TS.CHAL

Challenge UC204-12 Imperial Insert with Grub Screws with 3/4 inch Bore 47mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UC204-12 Imperial Insert with Grub Screws with 3/4 inch Bore 47mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$15.86 ex VAT
$15.86 ex VAT
Sale Sold out

Equivalent to: UC.204-12

In stock

Price Break
3+ $10.63
5+ $10.03
9+ $9.91
19+ $9.79
49+ $9.67
74+ $9.55
99+ $8.96
199+ $8.84
249+ $8.72
499+ $8.60
999+ $8.36

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Challenge - Good Quality
Inside Diameter:
19.05mm = 0.75 (3/4) inch
Style:
UC
Technical
Shaft Diameter d 3/4 inch
Outside Diameter D 47mm
Overall Width Bi 31mm
Inner Race Width Be 17mm
Back of Bearing to Centre Line n 12.7mm
Front of Bearing to Centre Line m 18.3mm
Dimension G 5mm
Grub Screws x 2 1/4 - 28UNF inch
Load Rating (Dynamic) 1000kg
Load Rating (Static) 630kg
Max Speed 4000 rev/min
Grease Nipple Thread Size M6
Working Temperature -30°C to +120°C
