• Challenge UC205-16 Imperial Insert with Grub Screws with 1 inch Bore 52mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge UC205-16 Imperial Insert with Grub Screws with 1 inch Bore 52mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge
1 3

SKU: UC.205-16.TS.CHAL

Challenge UC205-16 Imperial Insert with Grub Screws with 1 inch Bore 52mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UC205-16 Imperial Insert with Grub Screws with 1 inch Bore 52mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$16.60 ex VAT
$16.60 ex VAT
Sale Sold out

Equivalent to: UC.205-16

In stock

Price Break
3+ $11.12
5+ $10.49
9+ $10.37
19+ $10.24
49+ $10.12
74+ $9.99
99+ $9.37
199+ $9.24
249+ $9.12
499+ $8.99
999+ $8.74

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

UC Insert with Grub Screws: These normal-duty bearing units are fitted with a triple lip seal. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. Also available as a complete housing assembly.
Benefits: High tolerance to harsh environments, cost effective bearing, re-lubricatable, grub screw fixing

Brand / Quality:
Challenge - Good Quality
Inside Diameter:
25.4mm = 1 inch
Style:
UC
Technical
Shaft Diameter d 1 inch
Outside Diameter D 52mm
Overall Width Bi 34.1mm
Inner Race Width Be 17mm
Back of Bearing to Centre Line n 14.3mm
Front of Bearing to Centre Line m 19.8mm
Dimension G 5mm
Grub Screws x 2 1/4 - 28UNF inch
Load Rating (Dynamic) 1100kg
Load Rating (Static) 710kg
Max Speed 3400 rev/min
Grease Nipple Thread Size M6
Working Temperature -30°C to +120°C
