• Challenge UC215-48 Imperial Insert with Grub Screws with 3 inch Bore 130mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge UC215-48 Imperial Insert with Grub Screws with 3 inch Bore 130mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge
1 3

SKU: UC.215-48.TS.CHAL

Challenge UC215-48 Imperial Insert with Grub Screws with 3 inch Bore 130mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UC215-48 Imperial Insert with Grub Screws with 3 inch Bore 130mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$213.48 ex VAT
$213.48 ex VAT
Sale Sold out

Equivalent to: UC.215-48

In stock

Price Break
3+ $143.00
5+ $134.97
9+ $133.36
19+ $131.75
49+ $130.15
74+ $128.54
99+ $120.50
199+ $118.90
249+ $117.29
499+ $115.68
999+ $112.47

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Challenge - Good Quality
Inside Diameter:
76.2mm = 3 inch
Style:
UC
Technical
Shaft Diameter d 3 inch
Outside Diameter D 130mm
Overall Width Bi 77.8mm
Inner Race Width Be 32mm
Back of Bearing to Centre Line n 33.3mm
Front of Bearing to Centre Line m 44.5mm
Dimension G 12mm
Grub Screws x 2 7/16 - 20UNF inch
Load Rating (Dynamic) 5190kg
Load Rating (Static) 4190kg
Max Speed 1200 rev/min
Grease Nipple Thread Size M8
Working Temperature -30°C to +120°C
