• Challenge UC218-56 Imperial Insert with Grub Screws with 3-1/2 inch Bore 160mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge UC218-56 Imperial Insert with Grub Screws with 3-1/2 inch Bore 160mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge
1 3

SKU: UC.218-56.TS.CHAL

Challenge UC218-56 Imperial Insert with Grub Screws with 3-1/2 inch Bore 160mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UC218-56 Imperial Insert with Grub Screws with 3-1/2 inch Bore 160mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$445.27 ex VAT
$445.27 ex VAT
Sale Sold out

Equivalent to: UC.218-56

In stock

Price Break
3+ $298.25
5+ $281.50
9+ $278.15
19+ $274.80
49+ $271.44
74+ $268.09
99+ $251.34
199+ $247.99
249+ $244.63
499+ $241.28
999+ $234.58

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Challenge - Good Quality
Inside Diameter:
88.9mm = 3.5 (3-1/2) inch
Style:
UC
Technical
Shaft Diameter d 3-1/2 inch
Outside Diameter D 160mm
Overall Width Bi 96mm
Inner Race Width Be 37mm
Back of Bearing to Centre Line n 39.7mm
Front of Bearing to Centre Line m 56.3mm
Dimension G 12mm
Grub Screws x 2 1/2 - 20UNF inch
Load Rating (Dynamic) 7500kg
Load Rating (Static) 6170kg
Max Speed 950 rev/min
Grease Nipple Thread Size M10
Working Temperature -30°C to +120°C
