SKU: UCF320T04-SNR
SNR UCF320T04 Metric Four Bolt Square Cast Iron Flange Housing with 100mm Bore Insert Low Temperature Version - Allow 2-3 Days
SNR UCF320T04 Metric Four Bolt Square Cast Iron Flange Housing with 100mm Bore Insert Low Temperature Version - Allow 2-3 Days
Regular price
$1,738.20
ex VAT
Regular price
Sale price
$1,738.20
ex VAT
In stock
Price Break
3+
$1,242.60
4+
$1,177.20
9+
$1,111.80
19+
$1,046.40
49+
$1,020.24
99+
$994.08
499+
$863.28
999+
$0.00
1999+
$0.00
2999+
$0.00
4999+
$0.00
Quantity
Couldn't load pickup availability
Description
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 100mm
- Style:
- UCF
- Bolt Hole Centres:
- 242mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 100mm |
| A | 94mm |
| A1 | 32mm |
| A2 | 125mm |
| B | 108mm |
| e | 59mm |
| J | 242mm |
| L | 310mm |
| N | 38mm |
| S | 42mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 171.6 kN |
| Static load C0 | 140 kN |
| --- | Unit information |
| Operating temperature min. | -40°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 75 Nm |
| Mass | 25.6 kg |
