• UCFC204 Metric Four Bolt Cast Iron Round Flanged Housing with 20mm Insert
1 1

SKU: UCFC.204

UCFC204 Metric Four Bolt Cast Iron Round Flanged Housing with 20mm Insert

UCFC204 Metric Four Bolt Cast Iron Round Flanged Housing with 20mm Insert
$15.29 ex VAT
$15.29 ex VAT
Sale Sold out

In stock

Price Break
3+ $10.24
4+ $9.66
9+ $9.55
19+ $9.43
49+ $9.32
99+ $9.20
499+ $8.63
999+ $8.51
1999+ $8.40
2999+ $8.28
4999+ $8.05

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
20mm
Style:
UCFC
Pitch Circle Diameter:
78mm
Technical
d 20mm
a 100mm
P 78mm
e 55.1mm
i 10mm
L 25.5mm
s 12mm
j 5mm
k 7mm
g 20.5mm
f 62mm
z 28.3mm
Bi 31mm
n 12.7mm
Bolt Size M10
Weight 0.78 kg
Dynamic load 1000 kgf
Static load 630 kgf
