• UCFC204-12 Imperial Four Bolt Cast Iron Round Flanged Housing with 3/4 inch Insert
1 1

SKU: UCFC.204-12

UCFC204-12 Imperial Four Bolt Cast Iron Round Flanged Housing with 3/4 inch Insert

UCFC204-12 Imperial Four Bolt Cast Iron Round Flanged Housing with 3/4 inch Insert
$15.29 ex VAT
$15.29 ex VAT
Sale Sold out

In stock

Price Break
3+ $10.24
4+ $9.66
9+ $9.55
19+ $9.43
49+ $9.32
99+ $9.20
499+ $8.63
999+ $8.51
1999+ $8.40
2999+ $8.28
4999+ $8.05

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
19.05mm = 0.75 (3/4) inch
Style:
UCFC
Pitch Circle Diameter:
78.18mm = 78.18 (3-5/64) inch
Technical
d 3/4 inch
a 3-15/16 inch
P 3-5/64 inch
e 2-11/64 inch
i 25/64 inch
L 1 inch
s 15/32 inch
j 13/64 inch
k 9/32 inch
g 13/16 inch
f 2.4409 inch
z 1-1/8 inch
Bi 1.2205 inch
n 0.500 inch
Bolt Size 3/8 inch
Weight 0.78 kg
Dynamic load 1000 kgf
Static load 630 kgf
