• UCFC207-20 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-1/4 inch Insert
1 1

SKU: UCFC.207-20

UCFC207-20 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-1/4 inch Insert

UCFC207-20 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-1/4 inch Insert
$27.40 ex VAT
$27.40 ex VAT
Sale Sold out

In stock

Price Break
3+ $18.36
4+ $17.32
9+ $17.12
19+ $16.91
49+ $16.71
99+ $16.50
499+ $15.47
999+ $15.26
1999+ $15.06
2999+ $14.85
4999+ $14.44

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
31.75mm = 1.25 (1-1/4) inch
Style:
UCFC
Pitch Circle Diameter:
109.93mm = 109.93 (4-21/64) inch
Technical
d 1-1/4 inch
a 5-5/16 inch
P 4-21/64 inch
e 3-1/16 inch
i 7/16 inch
L 1-11/32 inch
s 35/64 inch
j 5/16 inch
k 11/32 inch
g 1-1/32 inch
f 3.5433 inch
z 1-7/16 inch
Bi 1.6890 inch
n 0.6890 inch
Bolt Size 7/16 inch
Weight 1.7 kg
Dynamic load 2010 kgf
Static load 1390 kgf
