• UCFC208-25 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-9/16 inch Insert
1 1

SKU: UCFC.208-25

UCFC208-25 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-9/16 inch Insert

UCFC208-25 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-9/16 inch Insert
$31.69 ex VAT
$31.69 ex VAT
Sale Sold out

In stock

Price Break
3+ $21.22
4+ $20.03
9+ $19.79
19+ $19.56
49+ $19.32
99+ $19.08
499+ $17.89
999+ $17.65
1999+ $17.41
2999+ $17.17
4999+ $16.69

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
39.69mm = 1.563 (1-9/16) inch
Style:
UCFC
Pitch Circle Diameter:
119.86mm = 119.86 (4-23/32) inch
Technical
d 1-9/16 inch
a 5-23/32 inch
P 4-23/32 inch
e 3-11/32 inch
i 7/16 inch
L 1-27/64 inch
s 35/64 inch
j 25/64 inch
k 11/32 inch
g 1-1/32 inch
f 3.9370 inch
z 1-5/8 inch
Bi 1.9370 inch
n 0.7480 inch
Bolt Size 7/16 inch
Weight 2 kg
Dynamic load 2560 kgf
Static load 1810 kgf
