• UCFC209 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert
1 1

SKU: UCFC.209

UCFC209 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert

UCFC209 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert
$40.10 ex VAT
$40.10 ex VAT
Sale Sold out

In stock

Price Break
3+ $26.86
4+ $25.35
9+ $25.05
19+ $24.75
49+ $24.45
99+ $24.15
499+ $22.64
999+ $22.33
1999+ $22.03
2999+ $21.73
4999+ $21.13

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
45mm
Style:
UCFC
Pitch Circle Diameter:
132mm
Technical
d 45mm
a 160mm
P 132mm
e 93.3mm
i 10mm
L 38mm
s 16mm
j 12mm
k 10mm
g 26mm
f 105mm
z 40.2mm
Bi 49.2mm
n 19mm
Bolt Size M14
Weight 2.8 kg
Dynamic load 2560 kgf
Static load 1810 kgf
