• UCFC209-26 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-5/8 inch Insert
1 1

SKU: UCFC.209-26

UCFC209-26 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-5/8 inch Insert

UCFC209-26 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-5/8 inch Insert
$48.67 ex VAT
$48.67 ex VAT
Sale Sold out

In stock

Price Break
3+ $32.60
4+ $30.77
9+ $30.40
19+ $30.04
49+ $29.67
99+ $29.30
499+ $27.47
999+ $27.10
1999+ $26.74
2999+ $26.37
4999+ $25.64

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
41.28mm = 1.625 (1-5/8) inch
Style:
UCFC
Pitch Circle Diameter:
132.16mm = 132.16 (5-13/64) inch
Technical
d 1-5/8 inch
a 6-5/16 inch
P 5-13/64 inch
e 3-43/64 inch
i 25/64 inch
L 1-1/2 inch
s 5/8 inch
j 15/32 inch
k 25/64 inch
g 1-1/32 inch
f 4.1339 inch
z 1-19/32 inch
Bi 1.9370 inch
n 0.7480 inch
Bolt Size 1/2 inch
Weight 2.8 kg
Dynamic load 2560 kgf
Static load 1810 kgf
