• UCFC210-30 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-7/8 inch Insert
1 1

SKU: UCFC.210-30

UCFC210-30 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-7/8 inch Insert

UCFC210-30 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-7/8 inch Insert
$46.88 ex VAT
$46.88 ex VAT
Sale Sold out

In stock

Price Break
3+ $31.40
4+ $29.64
9+ $29.28
19+ $28.93
49+ $28.58
99+ $28.23
499+ $26.46
999+ $26.11
1999+ $25.76
2999+ $25.40
4999+ $24.70

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
47.63mm = 1.875 (1-7/8) inch
Style:
UCFC
Pitch Circle Diameter:
138.11mm = 138.11 (5-7/16) inch
Technical
d 1-7/8 inch
a 6-1/2 inch
P 5-7/16 inch
e 3-27/32 inch
i 25/64 inch
L 1-9/16 inch
s 5/8 inch
j 15/32 inch
k 9/16 inch
g 1-3/32 inch
f 4.3307 inch
z 2.0315 inch
Bi 1-11/16 inch
n 0.7480 inch
Bolt Size 1/2 inch
Weight 3 kg
Dynamic load 2750 kgf
Static load 2020 kgf
