• UCFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Insert
1 1

SKU: UCFC.211

UCFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Insert

UCFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Insert
$105.02 ex VAT
$105.02 ex VAT
Sale Sold out

In stock

Price Break
3+ $70.35
4+ $66.39
9+ $65.60
19+ $64.81
49+ $64.02
99+ $63.23
499+ $59.28
999+ $58.49
1999+ $57.70
2999+ $56.91
4999+ $55.33

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
55mm
Style:
UCFC
Pitch Circle Diameter:
150mm
Technical
d 55mm
a 185mm
P 150mm
e 106.1mm
i 13mm
L 42mm
s 19mm
j 12mm
k 15mm
g 31mm
f 125mm
z 46.4mm
Bi 55.6mm
n 22.2mm
Bolt Size M16
Weight 4 kg
Dynamic load 3400 kgf
Static load 2550 kgf
