• UCFC211-32 Imperial Four Bolt Cast Iron Round Flanged Housing with 2 inch Insert
1 1

SKU: UCFC.211-32

UCFC211-32 Imperial Four Bolt Cast Iron Round Flanged Housing with 2 inch Insert

UCFC211-32 Imperial Four Bolt Cast Iron Round Flanged Housing with 2 inch Insert
$114.99 ex VAT
$114.99 ex VAT
Sale Sold out

In stock

Price Break
3+ $77.02
4+ $72.69
9+ $71.83
19+ $70.96
49+ $70.09
99+ $69.23
499+ $64.90
999+ $64.04
1999+ $63.17
2999+ $62.31
4999+ $60.58

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
50.8mm = 2 inch
Style:
UCFC
Pitch Circle Diameter:
150.02mm = 150.02 (5-29/32) inch
Technical
d 2 inch
a 7-9/32 inch
P 5-29/32 inch
e 4-11/64 inch
i 33/64 inch
L 1-21/32 inch
s 3/4 inch
j 15/32 inch
k 19/32 inch
g 1-7/32 inch
f 4.9213 inch
z 1-13/16 inch
Bi 2.1890 inch
n 0.8740 inch
Bolt Size 5/8 inch
Weight 4 kg
Dynamic load 3400 kgf
Static load 2550 kgf
