• UCFC213 Metric Four Bolt Cast Iron Round Flanged Housing with 65mm Insert
1 1

SKU: UCFC.213

UCFC213 Metric Four Bolt Cast Iron Round Flanged Housing with 65mm Insert

UCFC213 Metric Four Bolt Cast Iron Round Flanged Housing with 65mm Insert
$120.37 ex VAT
$120.37 ex VAT
Sale Sold out

In stock

Price Break
3+ $80.62
4+ $76.09
9+ $75.19
19+ $74.28
49+ $73.37
99+ $72.47
499+ $67.94
999+ $67.03
1999+ $66.13
2999+ $65.22
4999+ $63.41

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
65mm
Style:
UCFC
Pitch Circle Diameter:
170mm
Technical
d 65mm
a 205mm
P 170mm
e 120.2mm
i 16mm
L 50mm
s 19mm
j 14mm
k 15mm
g 36mm
f 145mm
z 55.7mm
Bi 65.1mm
n 25.4mm
Bolt Size M16
Weight 5.4 kg
Dynamic load 4480 kgf
Static load 3470 kgf
