• UCFC215 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert
1 1

SKU: UCFC.215

UCFC215 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert

UCFC215 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert
$227.27 ex VAT
$227.27 ex VAT
Sale Sold out

In stock

Price Break
3+ $152.24
4+ $143.69
9+ $141.97
19+ $140.26
49+ $138.55
99+ $136.84
499+ $128.29
999+ $126.58
1999+ $124.87
2999+ $123.16
4999+ $119.74

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
75mm
Style:
UCFC
Pitch Circle Diameter:
184mm
Technical
d 75mm
a 220mm
P 184mm
e 130.1mm
i 18mm
L 56mm
s 19mm
j 16mm
k 18mm
g 40mm
f 160mm
z 62.5mm
Bi 77.8mm
n 33.3mm
Bolt Size M16
Weight 7.3 kg
Dynamic load 5190 kgf
Static load 4190 kgf
