SKU: UCFC.216-50
UCFC216-50 Imperial Four Bolt Cast Iron Round Flanged Housing with 3-1/8 inch Insert
UCFC216-50 Imperial Four Bolt Cast Iron Round Flanged Housing with 3-1/8 inch Insert
Out of stock
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 79.38mm = 3.125 (3-1/8) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 200.03mm = 200.03 (7-7/8) inch
Technical
Technical
| d | inch |
|---|---|
| a | 9-7/16 inch |
| P | 7-7/8 inch |
| e | 5-9/16 inch |
| i | 45/64 inch |
| L | 2-9/32 inch |
| s | 29/32 inch |
| j | 5/8 inch |
| k | 23/32 inch |
| g | 1-21/32 inch |
| f | 6.6929 inch |
| z | 2-21/32 inch |
| Bi | 3.2520 inch |
| n | 1.3110 inch |
| Bolt Size | 5/8 inch |
| Weight | 8.9 kg |
| Dynamic load | 5700 kgf |
| Static load | 4550 kgf |
